So, you're thinking about squeezing an ITX build into that gorgeous Phanteks Evolv X case, huh? Great choice! The Evolv X is a fantastic case, known for its aesthetics and spacious interior, but let's be real, it's primarily designed for ATX motherboards. Stuffing a smaller ITX board in there requires a little planning and maybe an upgrade kit. That's where this guide comes in. We will walk you through everything you need to know, from understanding the challenges to selecting the right components and executing the build like a pro.

Understanding the ITX Upgrade for the Evolv X

First, let's address the elephant in the room: the Phanteks Evolv X wasn't really made for ITX boards. It's like putting a tiny house on a massive plot of land – you can do it, but you need to adapt. So, what are the main considerations when planning an ITX upgrade for this case?

• Size Difference: ITX boards are significantly smaller than ATX. This means you'll have a lot of empty space in the case. While this can be good for airflow, it also means you need to think about how to mount the ITX board securely and aesthetically.
• Mounting: The Evolv X is designed with ATX mounting points. You'll need an adapter or a specific ITX upgrade kit to properly mount the smaller board.
• Cable Management: Ironically, the extra space can make cable management trickier. You'll need to be strategic about routing cables to keep things clean and tidy.
• Cooling: While the Evolv X has excellent airflow, ITX builds can sometimes run hotter due to the compact components. Consider your cooling solutions carefully.

Don't worry, guys! It's all manageable. With the right approach, you can create a stunning and powerful ITX system inside the Evolv X.

Essential Components for Your ITX Upgrade

Okay, let's talk gear. Besides the core components of any PC build (CPU, RAM, storage, etc.), here are the key things you'll need to focus on for this specific ITX upgrade:

1. ITX Motherboard

This is the heart of your build. Choose a board that supports your desired CPU and has the features you need (Wi-Fi, USB ports, etc.). Research compatibility and read reviews before committing.

Things to consider:

• Chipset: Make sure the chipset supports your CPU (e.g., Intel Z690/Z790 or AMD B650/X670).
• Features: Do you need Thunderbolt, high-end audio, or multiple M.2 slots?
• Size Constraints: While all ITX boards are the same size (6.7 x 6.7 inches), some have larger VRM heatsinks or other components that might interfere with certain coolers or case layouts.

2. Phanteks Evolv X ITX Upgrade Kit

This is the most important part! Phanteks (or sometimes third-party manufacturers) offers ITX upgrade kits specifically designed for the Evolv X. These kits typically include:

• ITX Mounting Plate: This plate attaches to the Evolv X's motherboard tray and provides the necessary mounting points for your ITX board.
• Screws and Stand-offs: All the hardware you need to secure the board to the mounting plate.
• Sometimes: Cable management accessories or other helpful bits and pieces.

Note: Check the compatibility of the upgrade kit with your specific Evolv X model (original or revised) to avoid any issues.

3. CPU Cooler

Cooling is crucial in any build, but especially in ITX systems where space is limited. You have a few options:

• Low-Profile Air Cooler: These coolers are designed to fit in tight spaces and are a good option if you're not overclocking heavily. Noctua NH-L9i or be quiet! Shadow Rock LP are popular choices.
• AIO (All-in-One) Liquid Cooler: AIOs offer excellent cooling performance in a compact package. A 120mm or 140mm AIO should fit nicely in the Evolv X, especially mounted at the rear exhaust.
• Custom Loop (Advanced): For the hardcore enthusiasts! A custom loop offers the best cooling performance and aesthetics, but it's more complex and expensive.

Things to consider:

• TDP: Make sure the cooler can handle the thermal design power (TDP) of your CPU.
• Clearance: Check the cooler's height to ensure it doesn't interfere with RAM or other components.
• Fan Noise: Some coolers are quieter than others. Read reviews to get an idea of the noise levels.

4. Power Supply (PSU)

The Evolv X can accommodate both ATX and SFX power supplies. While an ATX PSU will work fine, an SFX PSU offers several advantages in an ITX build:

• Smaller Size: SFX PSUs are significantly smaller than ATX PSUs, freeing up valuable space for cable management and airflow.
• More Room for Components: The extra space can allow for larger coolers or more flexible component placement.

Things to consider:

• Wattage: Calculate your system's power requirements and choose a PSU with enough headroom.
• Modularity: A modular PSU allows you to detach unnecessary cables, further improving cable management.
• Efficiency: Look for a PSU with an 80+ Bronze or higher rating for better efficiency and lower heat output.

5. Case Fans (Optional but Recommended)

While the Evolv X has good airflow, adding a few extra case fans can further improve cooling, especially for an ITX build. Consider adding fans to the front intake and rear exhaust.

Things to consider:

• Size: The Evolv X supports 120mm and 140mm fans.
• Airflow: Choose fans with high airflow to maximize cooling.
• Noise: Look for fans with low noise levels for a quiet system.

Step-by-Step Guide to Installing Your ITX System in the Evolv X

Alright, let's get our hands dirty! Here's a step-by-step guide to installing your ITX system in the Evolv X:

1. Prepare the Case:

   • Remove any unnecessary components from the Evolv X, such as the ATX motherboard standoffs and any drive cages that might be in the way.
   • Install the ITX mounting plate from your upgrade kit. Follow the instructions that come with the kit.

2. Install the CPU, RAM, and M.2 SSD (if applicable) on the Motherboard:

   | Read Also : Level Up Your LinkedIn & Reddit Game With Pro Photos
   • Do this before installing the motherboard in the case. It's much easier to work on the board outside of the cramped confines of the Evolv X.

3. Mount the Motherboard:

   • Carefully align the ITX motherboard with the mounting points on the ITX mounting plate.
   • Secure the board with the screws and standoffs provided in the upgrade kit.

4. Install the CPU Cooler:

   • Follow the instructions that come with your CPU cooler.
   • Make sure the cooler is properly seated and secured.

5. Install the GPU:

   • Insert the graphics card into the PCIe slot on the motherboard.
   • Secure the card to the case with screws.

6. Install the PSU:

   • Place the PSU in its designated compartment in the Evolv X.
   • Secure it with screws.

7. Connect the Cables:

   • This is where cable management becomes crucial.
   • Connect the necessary cables to the motherboard, GPU, and storage devices.
   • Route the cables neatly behind the motherboard tray and through the cable management channels in the Evolv X.
   • Use zip ties or Velcro straps to secure the cables.

8. Install Storage Drives:

   • Install your SSDs or HDDs in the drive bays of the Evolv X.
   • Connect the SATA data and power cables.

9. Install Case Fans (if applicable):

   • Mount the case fans in the desired locations (front intake, rear exhaust, etc.).
   • Connect the fan cables to the motherboard or a fan controller.

10. Double-Check Everything:

    • Before powering on the system, double-check all connections to make sure everything is properly seated and secured.

11. Power On and Test:

    • Connect the power cord and turn on the system.
    • Enter the BIOS and make sure all components are recognized.
    • Install the operating system and drivers.
    • Run some stress tests to ensure the system is stable.

Cable Management Tips and Tricks

Cable management is essential for a clean and functional ITX build in the Evolv X. Here are some tips and tricks to help you keep things tidy:

• Plan Ahead: Before you start building, plan out your cable routing. Think about where each cable needs to go and how you can minimize clutter.
• Use Modular PSU Cables: As mentioned earlier, a modular PSU allows you to detach unnecessary cables, reducing clutter.
• Route Cables Behind the Motherboard Tray: The Evolv X has plenty of space behind the motherboard tray for cable routing. Use this space to your advantage.
• Use Cable Management Channels: The Evolv X also has built-in cable management channels that can help you keep cables organized.
• Use Zip Ties or Velcro Straps: Use zip ties or Velcro straps to secure cables and keep them from dangling.
• Hide Unused Cables: If you have any unused cables, hide them in the PSU shroud or behind the drive bays.

Troubleshooting Common Issues

Even with careful planning, you might encounter some issues during the build process. Here are some common problems and how to troubleshoot them:

• System Won't Power On:

  • Check the power cord and PSU switch.
  • Make sure the motherboard power connectors are properly connected.
  • Check the front panel connectors.

• No Display:

  • Make sure the monitor cable is connected to the GPU and not the motherboard.
  • Reseat the GPU.
  • Try a different monitor cable.

• Overheating:

  • Make sure the CPU cooler is properly installed.
  • Check the fan speeds.
  • Improve airflow by adding more case fans.

• Driver Issues:

  • Download the latest drivers from the manufacturer's website.
  • Make sure the drivers are compatible with your operating system.

Final Thoughts

Building an ITX system in the Phanteks Evolv X can be a rewarding experience. While it requires some planning and effort, the result is a powerful and aesthetically pleasing machine. By following this guide and taking your time, you can create a stunning ITX build that you'll be proud of. Good luck, and happy building!
