Creating a main menu is one of the fundamental steps in developing almost any game using Unity. A well-designed main menu not only provides players with options to start the game, adjust settings, or learn more about the game but also sets the tone and initial impression. This guide will walk you through the process of creating a simple yet functional main menu in Unity, covering everything from setting up the UI elements to scripting the necessary functionalities. So, let's dive right in and get your game started on the right foot!

Setting Up the Project and Scene

First things first, let's set up our Unity project to make sure we have a clean slate for our main menu creation. Open Unity and either create a new project or open an existing one where you want to add a main menu. If you're starting fresh, choose a 2D or 3D template based on your game's requirements.

Once your project is open, create a new scene. Go to File > New Scene. This new scene will be dedicated to your main menu. Save the scene with a descriptive name like "MainMenu" or "StartScreen" inside your project’s Assets folder, preferably under a dedicated folder like Assets/Scenes to keep things organized. Proper project organization from the start can save you a lot of headaches down the line. Name it something obvious so you can find it easily later. Good job, guys, you've set up the project!

With the scene created and saved, it’s time to set up the basic canvas for the UI. In the Hierarchy window, right-click and select UI > Canvas. A Canvas is the base object for all UI elements in Unity. It’s where all your buttons, text, and images will live. When you create a Canvas, Unity will automatically create an EventSystem object as well. The EventSystem is crucial for handling user input and interactions with the UI elements.

By default, the Canvas uses the Render Mode set to Screen Space - Overlay. This means the UI will be rendered on top of everything else in the scene. For main menus, this is generally what you want. However, you can also choose Screen Space - Camera if you want the UI to be rendered in front of a specific camera, or World Space if you want the UI to be part of the 3D world.

Next, adjust the Canvas Scaler component to handle different screen resolutions. Select the Canvas in the Hierarchy, and in the Inspector window, find the Canvas Scaler component. Change the UI Scale Mode from Constant Pixel Size to Scale With Screen Size. This ensures that your UI elements scale properly on different devices.

Set the Reference Resolution to a common resolution like 1920x1080. This is the resolution your UI is designed for, and the Canvas Scaler will scale the UI accordingly for other resolutions. Adjust the Screen Match Mode to Match Width Or Height and set the Match value to 0.5. This ensures a balanced scaling between width and height. These settings will help maintain the visual consistency of your main menu across various screen sizes, which is essential for providing a good user experience.

Adding UI Elements

Now that we have our scene and Canvas set up, let's add some UI elements to make our main menu functional. We’ll start with a background image, a title text, and some buttons for different actions such as starting the game, accessing settings, and quitting the game.

First, let’s add a background image to make our main menu visually appealing. In the Hierarchy window, right-click on the Canvas and select UI > Image. This will create a new Image object as a child of the Canvas. In the Inspector window, rename the Image object to “BackgroundImage”. To set the image source, click on the Source Image field and select a suitable image from your project’s assets, or drag an image from your project folder directly into the Source Image field. If you don’t have a specific image yet, you can use a solid color for now and replace it later. Adjust the Color property to your liking.

To make the background image fill the entire screen, set its Rect Transform properties. In the Inspector, set Anchor Presets to Stretch by holding Shift and Alt keys while clicking on the anchor box. This will stretch the image to cover the entire Canvas. Set Left, Top, Right, and Bottom values to 0 to ensure the image perfectly fills the screen. Ensure the image's Raycast Target is disabled to prevent it from interfering with button clicks.

Next, let's add a title text to the main menu. Right-click on the Canvas in the Hierarchy and select UI > Text - TextMeshPro. This will create a TextMeshPro Text object. If you haven’t used TextMeshPro before, Unity will prompt you to import the TextMeshPro essential resources. Follow the prompts to import them. TextMeshPro provides better text rendering and more customization options compared to the built-in Text component.

Rename the TextMeshPro Text object to “TitleText”. In the Inspector window, set the Text field to your game’s title. Adjust the Font Size, Font Style, and Color properties to your liking. A larger font size and a contrasting color will make the title stand out. Adjust the Alignment to center the text both horizontally and vertically.

Set the Rect Transform properties to position the title text at the top of the screen. Set Anchor Presets to Top Center by holding Shift and Alt keys while clicking on the anchor box. Adjust the Pos Y value to position the title text appropriately. For example, a Pos Y value of -100 will position the title text 100 units below the top center of the screen. Ensure the title is readable and aesthetically pleasing.

Now, let’s add some buttons for the main menu options. Right-click on the Canvas in the Hierarchy and select UI > Button - TextMeshPro. This will create a Button object with a TextMeshPro Text child. Rename the Button object to “StartButton”. In the Inspector window, navigate to the Button component and set the Transition to Color Tint. This will change the button’s color when it’s hovered over or clicked. Adjust the Normal Color, Highlighted Color, Pressed Color, and Disabled Color to your liking.

To change the button’s text, expand the “StartButton” object in the Hierarchy and select the TextMeshPro Text child. In the Inspector window, set the Text field to “Start”. Adjust the Font Size, Font Style, and Color properties to your liking. Ensure the text is readable and contrasts well with the button’s background color. Adjust the Alignment to center the text both horizontally and vertically.

Set the Rect Transform properties to position the button on the screen. Set Anchor Presets to Center by holding Shift and Alt keys while clicking on the anchor box. Adjust the Pos Y value to position the button appropriately. For example, a Pos Y value of 50 will position the button 50 units above the center of the screen. Adjust the Width and Height values to set the button’s size. Usually, values of 200 and 50 are decent.

Duplicate the “StartButton” object twice by pressing Ctrl+D (or Cmd+D on Mac). Rename the duplicated buttons to “SettingsButton” and “QuitButton”. Adjust their Text fields to “Settings” and “Quit” respectively. Adjust their Pos Y values to position them below the “StartButton”. For example, set Pos Y of “SettingsButton” to -50 and Pos Y of “QuitButton” to -150. Make sure the buttons are evenly spaced and visually appealing.

Scripting the Button Functionalities

With the UI elements in place, let's add some scripts to make our buttons functional. We’ll create a MainMenu script to handle the button click events. This script will include functions to start the game, open the settings menu, and quit the game.

In the Project window, create a new C# script. Right-click in the Project window, select Create > C# Script, and name it “MainMenu”. Double-click the script to open it in your code editor. Write the following code to handle the button click events. This script includes functions to start the game, open the settings menu, and quit the game:

using UnityEngine;
using UnityEngine.SceneManagement;
using UnityEngine.UI;

public class MainMenu : MonoBehaviour
{
    public string firstLevelSceneName = "Level1"; // Set this in the Inspector with the name of your first level scene

    public void StartGame()
    {
        SceneManager.LoadScene(firstLevelSceneName);
    }

    public void OpenSettings()
    {
        // You can implement settings opening logic here
        Debug.Log("Settings opened!");
        // For example, you might want to enable/disable a settings panel
        // settingsPanel.SetActive(true);
    }

    public void QuitGame()
    {
        Debug.Log("Quitting game!");
        Application.Quit();

    #if UNITY_EDITOR
        UnityEditor.EditorApplication.isPlaying = false;
    #endif
    }
}

Save the MainMenu script and return to the Unity editor. In the Hierarchy window, create a new empty GameObject by right-clicking and selecting Create > Empty. Rename the GameObject to “MainMenuHandler”. Drag the MainMenu script from the Project window onto the “MainMenuHandler” GameObject in the Hierarchy. This attaches the script to the GameObject, allowing it to manage the main menu functionalities.

Now, let’s connect the buttons to the script functions. Select the “StartButton” in the Hierarchy. In the Inspector window, find the Button component and click the + button under the On Click () list. Drag the “MainMenuHandler” GameObject from the Hierarchy into the None (Object) field. From the dropdown menu, select MainMenu > StartGame (). This connects the “StartButton” to the StartGame function in the MainMenu script.

Repeat this process for the “SettingsButton” and “QuitButton”. For the “SettingsButton”, connect it to the MainMenu > OpenSettings () function. For the “QuitButton”, connect it to the MainMenu > QuitGame () function. Ensure that each button is correctly linked to its corresponding function in the MainMenu script. With these connections in place, the buttons will now trigger the appropriate actions when clicked.

For the StartGame function to work correctly, you need to add your game scenes to the Build Settings. Go to File > Build Settings. Drag your main menu scene and your game scenes from the Project window into the Scenes In Build list. Ensure that the main menu scene is at the top of the list (index 0), as this will be the first scene loaded when the game starts.

Enhancing the Main Menu

Now that you have a basic main menu, let's look at some ways to enhance it and make it more visually appealing and user-friendly. Adding animations, sound effects, and transitions can significantly improve the user experience and make your game feel more polished.

First, let’s add some animations to the buttons. You can use Unity’s Animation system to create simple hover effects or more complex animations. For example, you can make the buttons slightly scale up when the mouse hovers over them. To do this, select the “StartButton” in the Hierarchy and go to Window > Animation > Animation. This will open the Animation window.

Click the Create button to create a new Animation Clip. Save the animation clip with a descriptive name like “StartButtonHover”. In the Animation window, click the Add Property button and select Rect Transform > Scale. This will add a keyframe for the button’s scale property. At the beginning of the timeline (time 0:00), set the scale to (1, 1, 1). At a later point in the timeline (e.g., time 0:10), set the scale to (1.1, 1.1, 1.1). This will create a simple scaling animation when the button is hovered over.

To trigger the animation when the button is hovered over, you’ll need to use a script. Create a new C# script named “ButtonHoverAnimation” and attach it to the “StartButton”. Write the following code to play the animation when the mouse enters and exits the button:

using UnityEngine;
using UnityEngine.EventSystems;

public class ButtonHoverAnimation : MonoBehaviour, IPointerEnterHandler, IPointerExitHandler
{
    public Animator animator;
    public string animationName = "StartButtonHover";

    void Start()
    {
        animator = GetComponent<Animator>();
    }

    public void OnPointerEnter(PointerEventData eventData)
    {
        animator.Play(animationName);
    }

    public void OnPointerExit(PointerEventData eventData)
    {
        animator.Play(animationName);
    }
}

Save the ButtonHoverAnimation script and return to the Unity editor. Select the “StartButton” in the Hierarchy. In the Inspector window, find the ButtonHoverAnimation component and drag the “StartButton” from the Hierarchy into the Animator field. This connects the Animator component to the script. For the record, you can add hover animation to other buttons. This is essential to provide the right feedback to the users.

Adding sound effects to the buttons can also enhance the user experience. You can add a simple click sound when the button is pressed. To do this, select the “StartButton” in the Hierarchy. In the Inspector window, add an Audio Source component by clicking Add Component > Audio > Audio Source. Drag an audio clip from your project’s assets into the AudioClip field. Uncheck the Play On Awake option. To play the sound when the button is clicked, modify the MainMenu script.

Open the MainMenu script in your code editor and add the following code to the StartGame, OpenSettings, and QuitGame functions:

public AudioSource buttonClickSound;

public void StartGame()
{
    buttonClickSound.Play();
    SceneManager.LoadScene(firstLevelSceneName);
}

public void OpenSettings()
{
    buttonClickSound.Play();
    // You can implement settings opening logic here
    Debug.Log("Settings opened!");
    // For example, you might want to enable/disable a settings panel
    // settingsPanel.SetActive(true);
}

public void QuitGame()
{
    buttonClickSound.Play();
    Debug.Log("Quitting game!");
    Application.Quit();

#if UNITY_EDITOR
    UnityEditor.EditorApplication.isPlaying = false;
#endif
}

Save the MainMenu script and return to the Unity editor. Select the “MainMenuHandler” GameObject in the Hierarchy. In the Inspector window, find the MainMenu component and drag the Audio Source component from the “StartButton” into the Button Click Sound field. Now, when you click the “StartButton”, you’ll hear a click sound.

Adding transitions between the main menu and the game scenes can create a smoother and more immersive experience. You can use Unity’s SceneManager to load scenes asynchronously and display a loading screen while the new scene is loading. To do this, create a new scene named “LoadingScreen”. Add a UI Image and a UI Slider to the “LoadingScreen” scene. The UI Image will serve as the background for the loading screen, and the UI Slider will indicate the loading progress.

Create a new C# script named “LoadingScreen” and attach it to a GameObject in the “LoadingScreen” scene. Write the following code to load the game scene asynchronously and update the UI Slider:

using UnityEngine;
using UnityEngine.SceneManagement;
using UnityEngine.UI;
using System.Collections;

public class LoadingScreen : MonoBehaviour
{
    public Slider loadingSlider;
    public string sceneName;

    void Start()
    {
        StartCoroutine(LoadSceneAsync(sceneName));
    }

    IEnumerator LoadSceneAsync(string sceneName)
    {
        AsyncOperation operation = SceneManager.LoadSceneAsync(sceneName);

        while (!operation.isDone)
        {
            float progress = Mathf.Clamp01(operation.progress / 0.9f);
            loadingSlider.value = progress;
            yield return null;
        }
    }
}

Save the LoadingScreen script and return to the Unity editor. Select the GameObject in the “LoadingScreen” scene and, in the Inspector window, find the LoadingScreen component. Drag the UI Slider into the Loading Slider field. Set the Scene Name field to the name of your game scene.

In the MainMenu script, modify the StartGame function to load the “LoadingScreen” scene instead of the game scene directly:

public void StartGame()
{
    buttonClickSound.Play();
    SceneManager.LoadScene("LoadingScreen");
}

By following these steps, you can create a main menu that is both functional and visually appealing. Remember to iterate on your design and test it on different devices to ensure a consistent user experience. Have fun, and happy game development!
